High Quality Selective Coating For Solar Collector China Manufacturer

FOB Reference Price:Get Latest Price
US $157-169 / Pieces | 2 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
sanghui
Model Number:
SH-WM04
Type:
Flat Panel
Application:
Solar Thermal
Pipe Material:
Copper
Product name:
solar collectors china Manufacturer
Pipe Material::
Copper
Head Tube::
Copper , 22X0.6mmx3
Riser Tube::
Copper, 8X0.5mmx6
Absorber Coating::
Blue Selective Coating
Glass Cover::
Low iron tempered glass
Frame::
Aluminum Alloy Plate
Back sheet:
galvanized steel
Dimension(mm):
2000*1000*80
Supply Ability
Supply Ability:
5000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
Wooden plate and carton container
Port
Shenzhen/Hongkong/Guangzhou
Lead Time :
7-15 days

High Quality Selective Coating For Solar Collector China Manufacturer

Product Description



What is Solar Hot water heat system for?




A. Heating your water with the pollution-free Solar Energy can well reduce your carbon footprint and protect the environment




B. The abundant solar thermal energy is a very good option to replace coal, propane, natural gas, and fossil fuel resources on the earth, making our future sustainable and brighter.


C. The Solar heating systems can largely reduce your monthly heating bill as they use the free fuel-sunshine to provide hot water to your homes and businesses.



How it works?

1. Solar water heating systems use solar collectors to capture sun's energy;

2. A non-freezing, heat-transfer fluid(or water) in the collectors is heated;

3. The fluid is then circulated from the collectors and transferred the heat to the water in storage tank;

4. The hot water run out of the water tank and flow into the house and business building;

5. The solar fluid is then back to the collector and reheated.

Different systems of active/passive:

(1) Active solar water heating systems:

  The active solar water heating systems have circulating pumps and controls, and usually the water storage tank can be installed in garage or on the ground.




(2) Passive solar water heating systems:

 The passive solar water heating systems have two basic types:

     The integral collector-storage passive systems and thermosyphon systems:

For integral collector-storage passive systems, these work best in areas where temperatures rarely fall below freezing.

     For thermosyphon systems, the collectors and water storage tank must be installed both on the roof. These systems are reliable, but contractors must pay careful attention to the roof design because of the heavy storage tank.




SOLUTIONS

A solar water heating system can offset up to 75% of water heating energy costs. A solar water heater can cut a business' water heating costs by 50 to 85 percent, while demonstrating your commitment to a cleaner environment.

RESIDENTIAL---Resort/Villa


Specification:

Dimensions

2000mm*1000mm*80mm

Weight

30kg

Aperture Area

1.85 Square Meter

Working pressure

0.6 MPA

Collect port

H Shape

Collect port material

(TP2)

Head tube

Φ22*0.6mm*3pcs

Grid tube

Φ8*0.5mm*6pcs

Absorber Coating

Selective coating whole plate

Absorptivity

≥96%±2

Emissivity

≤4.6%±2

Bonding technology

Laser Bonding

Cover

3.2mm low iron tempered  glass

Light Transmission

≥91.8%

Insulating layer

Fiber Glass \ 40mm*40K

Frame

6063 Aluminum alloy

Interface Port

1/2 external thread

Plate core volume

1.5 L






Packaging & Shipping

 Wooden plate and carton container
